Prefab House Precast Composite Partition Sandwich Wall Panel

China Prefab House Precast Composite Partition Sandwich Wall Panel supplier
Prefab House Precast Composite Partition Sandwich Wall Panel supplier Prefab House Precast Composite Partition Sandwich Wall Panel supplier Prefab House Precast Composite Partition Sandwich Wall Panel supplier Prefab House Precast Composite Partition Sandwich Wall Panel supplier

Large Image :  Prefab House Precast Composite Partition Sandwich Wall Panel

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: 75mm EPS Panel

Payment & Shipping Terms:

Minimum Order Quantity: 1x20 GP
Price: negotiation
Packaging Details: 1. free package (normal pallet + belt ) 2 .standard package (good pallet+corner protect paper +plastic thin film )
Delivery Time: 7-10 working days after received advanced payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 200,000 m2 per month
Detailed Product Description
Raw Material: EPS, Sand/fly Ash, Cement, Additives Size (L*W*T): 2270mm X 610mm X 60mm (75,60,100,120,150)
Sound Insulation: 46dB Fireproof: 240 Minutes – Class A
Anchorage Load: 50kg Certification: ISO/BV/CE/
Waterproof: Good Construction Time: 3 Workers Can Install 75m2 A Day
Eco-friendly: 100% No Asbestos, Asbestos Free

Prefab House Precast Composite Partition Sandwich Wall Panel



eps-sandwich-wall-panel


Name

Size(L*W*T)mm

Weight (kg/m2)

Packing(pcs/m2 20’GP)

Application

EPS Cement sandwich wall panel


2270x610x60

45-48

315 pcs /436 m2

Roof, interior wall

2270x610x75

50-53

252pcs / 349 m2

Interior wall

2270x610x90

55-58

207pcs / 287 m2

Interior/exterior wall

2270x610x100

60-65

189pcs / 262 m2

Interior/exterior wall

2270x610x120

65-75

153pcs / 212 m2

Exterior wall

2270x610x150

80-90

126pcs / 175 m2

Exterior wall


3 . Usage : Interior and exterior wall,roof ceiling and floor .
 Prefab House Precast Composite Partition Sandwich Wall Panel
Prefab House Precast Composite Partition Sandwich Wall Panel
4 . Advantages of Sandwich wall panel

 Energy-saving
 Light weight
 Sound insulation
 Environmental protection
 Most area-saving
 Most waterproof and dampproof
 Most fire-proof:
 Most sound-insulation
 Best hanging force
 Most anti-seismic and impact resistance
 Largest span and height thin webbed wall
 Most civilized, environmental, high efficiency construction.

5 . Technical Data:


Technology index

Metal frame and plaster boad

VJ EPS Panel

GRC Board

Gypsum block

Weight

20kg/m2

35kg/m2(60mm thickness)

40kg/m2

45kg/m2

Sound insulation

Almost no

excellent,46dB

normal

poor

Waterproof

poor

excellent

normal

poor

Heat insulation

no

excellent

normal

normal

Anti-impact capacity/Hanging force

no

high impact single hanging force is 50KGS

can impact,good hanging force

can impact,normal hanging force

Decoration difficulty

hard,with limiations

easy and without any limiations

General difficulty

General difficulty

Wall thickness

91mm

60mm,increased interior space

60mm

75mm

Useful life

2-3 years

60-70 years

20-30 years

15-20 years

Material secondary use

no

80% can be used

some available

almost no

Construction efficiency

faster

fast

faster

faster


eps-sandwich-wall-panel



FAQ
Q 1 ). How many years your company has been in this field?

A: More than 10 years of manufacturing EPS concrete sandwich wall panel,
now we are TOP 1 In middle of China, and among top 2 in china in this field .

Q2 ).Where is your main market of VANJOIN?

A: Main market Asia, South America, Africa,South East Asia is our largest market,Mid East is our second largest market.

Q3 ). Exporting details :

A: Loading & shipping 400 x 20 GP each month.

Q4 ). More information of VANJOIN factory?

A: land area 30,000 m2 machines, full-automatic production line Productivity: 2,000,000 m2 wall panel per year.

Q5 ). How could i get the samples?

A: We send you the free samples, catalogues, CD, but the Express charge is required,if you have the DHL, TNT, UPS, FedEx account, this is the best.
If not, you can transfer money to our Western Union, then we will send you.


 eps-sandwich-wall-panel



Factory Information

Production area is 40,000m2

Stacking area is 60,000m2

Production capacity is 2,000,000m2 per year

Export quantity is over 400 containers per month


Prefab House Precast Composite Partition Sandwich Wall Panel


 Prefab House Precast Composite Partition Sandwich Wall Panel
