annual 500000 m2 eps sandwich panel production line / sandwich making machine

China annual 500000 m2 eps sandwich panel production line / sandwich making machine supplier
annual 500000 m2 eps sandwich panel production line / sandwich making machine supplier annual 500000 m2 eps sandwich panel production line / sandwich making machine supplier annual 500000 m2 eps sandwich panel production line / sandwich making machine supplier annual 500000 m2 eps sandwich panel production line / sandwich making machine supplier

Large Image :  annual 500000 m2 eps sandwich panel production line / sandwich making machine

Product Details:

Place of Origin: Hubei, China(Mainland)
Brand Name: Vanjoin
Certification: ISO9001, ISO14001
Model Number: VJB-WPE008JM

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: standard export package
Delivery Time: 30-45 days after receiving prepayment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 sets per month
Detailed Product Description
Product Name: Sandwich Panel Production Line Type: Semi Automatic,Full Automatic
Advantage: High Output, Easy Maintenance, Long-term Professional Services Life Time: More Than 20 Years
Warranty: 1 Year Color: Customized

Annual 500000 m2 eps sandwich panel production line / sandwich making machine



1.Our machine can produce 8 kinds of sandwich panel :

  • EPS cement sandwich panel
  • Solid eps cement sandwich panel
  • Ceramisite sandwich panel
  • Solid Ceramisite sandwich panel
  • Perlite sandwich panel
  • Solid perlite sandwich panel
  • Eps & Ceramicite Sandwich Panel
  • Solid Eps & Ceramicite Sandwich Panel



2. Specification of annual 500000 m2 eps sandwich panel production line / sandwich making machine


VJ-HT2270
Name Main Parameters
Overall Dimensions(L*W*H) 3180*1380*3480mm
Weight 2800KG
Mobie Power(KW) 2.2
Mobie Speed(m/min) ≤60
Main Components Host chassis assembly (power device), former stands, after stands, after plate, rod
Accessories pressing plate, side mould
Production Information Thickness (mm) Width (mm) Length (mm) Quantity (pcs/set) Area (m2/set) Raw Material (m2)
60 610 2270 60 83.0 4.15
75 610 2270 50 69.2 4.50
90 610 2270 42 58.1 4.65
100 610 2270 40 55.3 4.98
120 610 2270 34 47.0 5.17
150 610 2270 28 38.7 5.42
180 610 2270 22 30.4 5.77





3. Advantages of annual 500000 m2 eps sandwich panel production line / sandwich making machine

(1) One-key intelligent operation

(2) Unique Operation Software

(3) Addictives (with patent)

(4) Measuring precisely ensuring each panel is with exactly same materials and ratio

(5) Easy maintenance by demounting the broken piece

(6) Recycling use the eps foam& eco-friendly

(7) Use local resources to reduce your production cost

(8) Professional after-services



4.Parameters for annual 500000 m2 EPS sandwich panel machine

Item No. VJ-II
Rated current 2.44A
Rated power 1.1 KW
Voltage 380V3-
Working mode S1
Machine Type 2W-7
Capacity 1.25m3/ hour
Dimension(L*D*H) 3200X146X2800
Weight(kg) 2800
Stroke speed

<30 meter/minute





5.Main System of after-sales service provided annual 500000 m2 EPS sandwich panel machine

  • EPS foaming system includes boiler, eps foaming machine, etc.
  • Raw materials storage/measuring/conveying system includes raw materials silo, storage& weighing &measuring hopper, pump, etc.
  • Mixing system includes mixing machine, electric control system, etc.
  • Forming and gating systes includes mould machine ,vibration machines, etc.

annual 500000 m2 eps sandwich panel production line / sandwich making machineannual 500000 m2 eps sandwich panel production line / sandwich making machineannual 500000 m2 eps sandwich panel production line / sandwich making machine
