Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel

Certification
Good quality EPS Cement Sandwich Panel for sales
Good quality EPS Cement Sandwich Panel for sales
Customer Reviews
I thought no body cares about others any more,but you changed this.

—— Mana AI Yaseen,Saudi Arabia

I appreciate very much your very kind attention to may request and it give to me a very strong confidence in your company in your services

—— Alfredo Friedmann,Paraguay

You are so kind and good service.

—— Samuel,Indonesia

You are star.I want to be your friend

—— Gert,South Africa

I'm Online Chat Now

Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel

China Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel supplier
Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel supplier Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel supplier Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel supplier

Large Image :  Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJ-WP-AY120

Payment & Shipping Terms:

Minimum Order Quantity: 300m2
Price: negotiation
Packaging Details: Standard Exporting Packing with EPE foam film,plastic thin film, edge protect, packing belt, good pallet.
Delivery Time: 7 working days after receiving prepayment.
Payment Terms: L/C, T/T
Supply Ability: 200,000m2/month
Detailed Product Description
Features: Thermal Insulation, Sound Insulation Face Board: Calcium Silicate Board
Cor Materials: EPS, Cement, Sand, Additives Standard Thickness: 60mm, 75mm, 90mm, 100mm, 120mm, 150mm
Sound Insulation: 46dB Lifespan: 70 Years
Usage: Interior Wall, Exterior Wall, Flooring, Roofing

Commercial Frame Light Weight Concrete Composite Boards With Cement Panel


Type

Sandwich wall panel

Material

Face boards are calcium silicate board, inner materials are eps foam, cement, sand, additives, etc.

Size

Standard length 2270mm, width 610mm, thickness 60mm,75mm,90mm,100mm,120mm,150mm.

Application

External and internal wall for various houses and buildings

Joining Method

Tongue & groove type

Supply ability

200,000m² per month.

Delivery time

Usually 3 days after receiving prepayment.

Payment terms

T/T, L/C.














 Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel
Specification and Weight and Loading Information




Name

Size(L*W*T)MM

Weight(KG)

Loading(PCS/M2 per 20ft)



Fast Installation Composite Panel Board Durable Sandwich Wall Panel

2270*610*60

45-48

315 pcs / 436

2270*610*75

50-53

252 pcs / 349

2270*610*90

55-58

207 pcs / 287

2270*610*100

60-65

189 pcs / 262

2270*610*120

65-75

153 pcs / 212

2270*610*150

90-90

126 pcs / 175




Strengths


Lightweight

1 person can carry panel easily

Eco-friendly

100% non-asbestos

Fast Construction

3 workers can install 60-80m2 per day

Strong,Durable and Long Lifespan

70 years

Sound Insulation

42-46 dB

Windproof

65m/s

Fireproof

4 hours

Anti-earthquake

Grade 8-9

Best hanging force

Single point hanging force is 50kg

Weight capacity

650KG / square meter

Commercial Frame Light Weight Concrete Composite Panel Board With Cement Panel



 Installation Process

1). Setting the line and carring the board in position
2). Sawing board
3). Sizing, sizing cement mortar on the side of panels
4). Installation, carry panel, correct panel and fix panel
5). Correcting and fixing
6). Grouting and filling starch
7). Sticking fiberglass mesh
8). installing electricity wire and switches
9). Installing doorcase
10). Facing coating and wall papers
11). Facing flexible soft ceramic tile
12). Electric apparatus installation
