CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery

China CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery supplier
CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery supplier CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery supplier CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery supplier CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery supplier

Large Image :  CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery

Product Details:

Place of Origin: Wuhan City, Hubei Province, Chian Mainland
Brand Name: VANJOIN
Certification: CE/BV/ISO9001/ISO14001/
Model Number: VJB-PL-02

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets/ units
Price: negotiation
Packaging Details: Standard exporting packing
Delivery Time: 20 - 35 days
Payment Terms: L/C,T/T, Paypal, Western Union, MoneyGram, D/A, D/P
Supply Ability: 20 Set/Sets per Month
Detailed Product Description
Features: Fast Construction, Anti-earthquake Product Name: CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery
Color: Red, Grey, Blue, Customer Design Material: Metal
Panel Use For: Exterior Wall, Interior Wall, Roof, Floor Proudcts: Vertical, Boiler, Foamin Machines, Etc
Loading: 20' GP Service Life: 20 Years
Shipping With: Compression Mould After-sales Service Provided: Engineers Available To Service Machinery Overseas

CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery



1 . Production Data of Wall Panel Forming Machine:



Specification(L*W*T) Output of One Mould Car
2270mm*610mm*60mm 60 pcs/set
2270mm*610mm*75mm 50 pcs/set
2270mm*610mm*90mm 42 pcs/set
2270mm*610mm*100mm 40 pcs/set
2270mm*610mm*120mm 34 pcs/set
2270mm*610mm*150mm 28 pcs/set
2270mm*610mm*180mm 22 pcs/set





. Features of Wall Panel Forming Machine



Light weight

1 person can take up two pieces of vanjoin panel

Energy-saving, Eco-friendly

100% non-asbestos

Easy to install, fast construction

3 workers can finish a 70 m2 house just by 1 week

Strong and durable

Long life 60-70 years

Heat insulation and preservation

Thermal conductivity: 0.221W/mk

Sound insulation

42-46 DB

Weatherproof; windproof

70m/s; grade 13

Fireproof

keep well about 4 hours under 1000 degree temperature

Anti-impact, anti-earthquake

Grade 8

Best hanging strength

Single point hanging force is > 1200 N

Weight capacity

400KG / square meter





3 . Workers and Area Requirement of Wall Panel Forming Machine



Annual Production Capacity Workers Requirement Production Area Requirement
100,000 m2 42595 500m2
200,000 m2 42661 600m2
300,000 m2 42724 700m2
400,000 m2 15-23 800m2
500,000 m2 18-28 900m2
600,000 m2 22-32 1000m2
700,000 m2 25-35 1100m2
800,000 m2 28-38 1200m2
900,000 m2 32-42 1300m2
1,000,000 m2 35-46 1400m2





4 . Technical Information of Wall Panel Forming Machine:



Vertical Automatic Mould Technical Parameters:

Name

Main Parameters

Overall Dimensions

3180 × 1380 × 3480

(Length × Width × Height)

Weight

2800 KGS

Mobile Power(KW)

2.2

Mobile Speed(m/min)

≤60

Main Components

Host

Chassis assembly(power device), former stands,

after stands, after plate, rod

Accessories

Press mould, side mould, bottom mould.

Production

Thickness

Width

Length

Quantity

Area

Raw Material

Information

(mm)

(mm)

(mm)

(pcs/set)

(m2/set)

(m3)

60

610

2270

48

66.5

3.32

75

610

2270

42

58.2

3.78

90

610

2270

36

49.8

3.99

100

610

2270

32

44.3

3.99

120

610

2270

30

41.5

4.57

150

610

2270

24

33.2

4.65

180

610

2270

20

27.7

4.71

Remarks

Two transition cars, production line conversion use, one set cheer machine,

spray release agent use, pour table, track

(the height of the mould cab be customized by customers specific requirements)







 5 . Why Choose VANJOIN Production Line?



v  Save freight: no high transportation cost



v  Fast delivery: no long waiting for the goods



v  Easy handling: no import procedures



v  More profit: win first value in aim market





 6 . Outstanding Advantages:



v Measuring precisely ensuring each panel is with exactly same materials and ratio



v Easy maintenance by demounting the broken piece



v Recycling use the eps foam& eco-friendly



v Taking good use of local resources: sand



v Fully closed working ensuring clear factory with less pollution


7 . What You Can Get from Us?



v Over 20 years service life



v Maintenance time: 1 year



v Fully automatic production system



v Professional installation service



v High output with less workers



v Unique Operation Software



v Unique Addictives





8 . Extra Free Service of Construction Material Making Machinery



Investment cost calculation



Factory area design



Production line layout design



Production capacity calculation



Provide engineers for installation and guidance on-site



 CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery



CE Expand Polystyrene Concrete EPS Cement Sandwich Wall Panel Machinery
