EPS foaming system Sandwich Panel Production Line , Moulding car machinery

China EPS foaming system Sandwich Panel Production Line , Moulding car machinery supplier
EPS foaming system Sandwich Panel Production Line , Moulding car machinery supplier EPS foaming system Sandwich Panel Production Line , Moulding car machinery supplier EPS foaming system Sandwich Panel Production Line , Moulding car machinery supplier EPS foaming system Sandwich Panel Production Line , Moulding car machinery supplier

Large Image :  EPS foaming system Sandwich Panel Production Line , Moulding car machinery

Product Details:

Place of Origin: Hubei, China(Mainland)
Brand Name: Vanjoin
Certification: ISO9001, ISO14001
Model Number: VJB-WPE016JM

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: standard export package
Delivery Time: 30-45 days after receiving prepayment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 sets per month
Contact Now
Detailed Product Description
Product Name: Sandwich Panel Production Line Type: Manual,Semi Automatic,Full Automatic
Advantage: High Output, Easy Maintenance Life Time: More Than 20 Years
Warranty: 1 Year Voltage: 220V Or 380V



EPS foaming system Sandwich Panel Production Line , Moulding car machinery



1.Our machine can produce 8 kinds of sandwich panel :

  • EPS cement sandwich panel
  • Solid eps cement sandwich panel
  • Ceramisite sandwich panel
  • Solid Ceramisite sandwich panel
  • Perlite sandwich panel
  • Solid perlite sandwich panel
  • Eps & Ceramicite Sandwich Panel
  • Solid Eps & Ceramicite Sandwich Panel



2. Specification of EPS foaming system sandwich panel production line


VJ-HT2270
Name Main Parameters
Overall Dimensions(L*W*H) 3180*1380*3480mm
Weight 2800KG
Mobie Power(KW) 2.2
Mobie Speed(m/min) ≤60
Main Components Host chassis assembly (power device), former stands, after stands, after plate, rod
Accessories pressing plate, side mould
Production Information Thickness (mm) Width (mm) Length (mm) Quantity (pcs/set) Area (m2/set) Raw Material (m2)
60 610 2270 60 83.0 4.15
75 610 2270 50 69.2 4.50
90 610 2270 42 58.1 4.65
100 610 2270 40 55.3 4.98
120 610 2270 34 47.0 5.17
150 610 2270 28 38.7 5.42
180 610 2270 22 30.4 5.77





3. Advantages of EPS foaming system sandwich panel production line

(1) One-key intelligent operation

(2) Unique Operation Software

(3) Addictives (with patent)

(4) Measuring precisely ensuring each panel is with exactly same materials and ratio

(5) Easy maintenance by demounting the broken piece

(6) Recycling use the eps foam& eco-friendly

(7) Use local resources to reduce your production cost

(8) Professional after-services



4.Parameters for EPS foaming system sandwich panel production line

Item No. VJ-II
Rated current 2.44A
Rated power 1.1 KW
Voltage 380V3-
Working mode S1
Machine Type 2W-7
Capacity 1.25m3/ hour
Dimension(L*D*H) 3200X146X2800
Weight(kg) 2800
Stroke speed

<30 meter/minute





5.Main System of EPS foaming system sandwich panel production line

  • EPS foaming system includes boiler, eps foaming machine, etc.
  • Raw materials storage/measuring/conveying system includes raw materials silo, storage& weighing &measuring hopper, pump, etc.
  • Mixing system includes mixing machine, electric control system, etc.
  • Forming and gating systes includes mould machine ,vibration machines, etc.

EPS foaming system Sandwich Panel Production Line , Moulding car machineryEPS foaming system Sandwich Panel Production Line , Moulding car machineryEPS foaming system Sandwich Panel Production Line , Moulding car machinery
