Product Details:
Payment & Shipping Terms:
|
| Types: | EPS Cement Sandwich Panels | Application: | Interior And Exterior Wall, Roof And Floor |
|---|---|---|---|
| Thickness: | 60, 75, 90, 100, 120, 150mm | Sound Insulation: | 38dB-46dB |
| Non-combustibility: | Grade A, BS EN ISO1182:2002 | Waterproof: | Good |
| Light Weight: | 1/6 Of Traditional Brick | Fireproof: | 4 Hours FRP |
| Anti-seismic: | 7-8 Class | Heat Insulated: | Good |
Energy Saving EPS Cement Sandwich Panel , Concrete Wall Board Easy Decoration
Vanjoin lightweight EPS(expandable polystyrene beads) sandwich panels is a kind of light weight
fireproof sound insulation fast construction easy decoration building materials. This panel
can be widely applied to interior wall, exterior wall, roof, floor and fence system for house,
school, hotel, hospital, warehouse, shopping mall ect. which can replace construction materials
like red brick, clay solid brick, air brick, color-coated steel sandwich wall board, gypsum block, wire
spatial grid structure perlite board and perlite porous board.
I. Composite of Vanjoin EPS Cement Sandwich Panels
Vanjoin lightweight EPS Cement Sandwich Wall Panel take 5mm thickness Calcium Silicon Board as
surface panel, with EPS(expandable polystyrene beads), Cement, sand, addictives as core material.
II. Application of Vanjoin EPS Cement Sandwich Panels
III. Main Features of Vanjoin EPS Cement Sandwich Panels
1. Light weight
The weight of Vanjoin EPS Sandwich Wall Panel is only 1/6 of traditional brick
2. Fireproof
Our sandwich panel approved fireproof test for 4 hours 1000 degree; got Grade A(GB/T9987).
3. Area-saving
Comparing with tradition building materials, you can save 4m2 per 100m2, if using our sandwich panel.
4. Waterproof
Good waterproof perfermance. No droplets observed behind the panel, test 24 hours at 250mm water.
5. Sound-insulation
Excellent acoustic perfermance 38dB-46dB, 38dB for 60mm thickness panel, 46dB for 150mm panel.
6. Fast and easy construction, Labor saving
Two experienced workers installation one day, they can install 75-80m2.
7. Long life usage:70 years
IV. Specification of Vanjoin EPS Cement Sandwich Panels
| Length | Width | Thickness | Weight | Application |
|---|---|---|---|---|
| 2270mm | 610mm | 60mm | 45-48kg/㎡ | Roof |
| 75mm | 50-53kg/㎡ | Interior wall | ||
| 90mm | 55-58kg/㎡ | Interior / Exterior wall | ||
| 100mm | 60-65kg/㎡ | Interior / Exterior wall | ||
| 120mm | 65-75kg/㎡ | Exterior wall | ||
| 150mm | 80-90kg/㎡ | Exterior wall | ||
| Allowed Tolerance: Length±5mm; Width±2mm; Thickness±1mm; Diagonal±2mm | ||||
Remark: All kinds of EPS sandwich wall panel can be customized by customers' specific requirements,
such as density and length of panels.
V. Packing Size & Details of Vanjoin EPS Cement Sandwich Panels
| Length | Width | Thickness | Packing Size of 20' GP Container |
| 2270mm | 610mm | 60mm | 315pcs / 436m2 |
| 75mm | 252pcs / 349m2 | ||
| 90mm | 207pcs / 287m2 | ||
| 100mm | 189pcs / 262m2 | ||
| 120mm | 153pcs / 212m2 | ||
| 150mm | 126pcs / 175m2 | ||
| Packing Details | 1. Free packing | with normal pallet and packing belt | |
| 2. Standard exporting packing | wrapped with plastic thin film,wedge protect & good pallet | ||
| 3. Packing size: | 1500-3000*610*1000mm | ||
| 4. Loading | 18 pallets per 20' container | ||
VI. Vanjoin EPS Cement Sandwich Panels Engineer Project
