Fast Installation Composite Panel Board Durable Sandwich Wall Panel

China Fast Installation Composite Panel Board Durable Sandwich Wall Panel supplier
Fast Installation Composite Panel Board Durable Sandwich Wall Panel supplier Fast Installation Composite Panel Board Durable Sandwich Wall Panel supplier Fast Installation Composite Panel Board Durable Sandwich Wall Panel supplier Fast Installation Composite Panel Board Durable Sandwich Wall Panel supplier Fast Installation Composite Panel Board Durable Sandwich Wall Panel supplier

Large Image :  Fast Installation Composite Panel Board Durable Sandwich Wall Panel

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJ-WP-AY011

Payment & Shipping Terms:

Minimum Order Quantity: 300m2
Price: negotiation
Packaging Details: Standard Exporting Pallet Packing
Delivery Time: 7 working days
Payment Terms: T/T, L/C
Supply Ability: 200,000m2 per month
Contact Now
Detailed Product Description
Size: 2270*610*60mm / 75mm / 90mm / 100mm / 120mm / 150mm Windproof: 65m/s
Fireproof: 4 Hours Soundproof: 46dB
Usage: Interior Wall, Exterior Wall Application: Various Houses And Buildings
Panel Type: Composite Panel Advantage: Eco-friendly,Non-asbestos
Certification: CE,ISO,,BV

Fast Installation Composite Panel Board Durable Sandwich Wall Panel



1. Composition



Face board  Both sides are calcium silicate board
Core materials  eps foam, cement, sand, additives



2. Specification and Weight and Loading Information





Name

Size(L*W*T)MM

Weight(KG)

Loading(PCS/M2 per 20ft)



Fast Installation Composite Panel Board Durable Sandwich Wall Panel

2270*610*60

45-48

315 pcs / 436

2270*610*75

50-53

252 pcs / 349

2270*610*90

55-58

207 pcs / 287

2270*610*100

60-65

189 pcs / 262

2270*610*120

65-75

153 pcs / 212

2270*610*150

90-90

126 pcs / 175



3. Advantages



Lightweight

1 person can carry panel easily

Eco-friendly

100% non-asbestos

Fast Construction

3 workers can install 60-80m2 per day

Strong,Durable and Long Lifespan

70 years

Sound Insulation

42-46 dB

Windproof

65m/s

Fireproof

4 hours

Anti-earthquake

Grade 8-9

Best hanging force

Single point hanging force is 50kg

Weight capacity

650KG / square meter



4. Performance



Flexural Strength(longitudianal)

4.27 MPa

Flexural Strength(transverse)

4118N

Moisture Movement

0.06%

Moisture Content

9%

Resistance to continuous heating

80 °c

Surface Alkalinity

pH 7-10

Non-combustibility(face Boards)

BS EN ISO 1182: 2002
BS476: Part 4
GB8624-1997, Grade A

Heat of combustion(face boards)

BS EN ISO 1716: 2002

Building regulations classification(face boars)

Euro Class A1

Fire rated partition

2 hour FRP
BS EN 1364-1
BS 476: Part 22
GB/T9978

Water tightness to ASTM C1185

No droplets observed behind the panel,
Test of 24 hours at 250 mm water head

Partition stiffness-heavy duty grade
(BS 5234; Part2: 1992, Annex A)

Pass

Resistance to substructure damage by multiple impacts
from a large soft body
-heavy duty grade( BS 5234; Part2: 1992, Annex E)

No collapse of dislocation

Surface damage by hard body impact- heavy duty grade
(BS 5234; Part2: 1992, Annex B)

Pass

Effects of door slamming-heavy duty grade
BS 5234; Part2: 1992, Annex B

Pass

resistance to crowd pressure-heavy duty grade
BS 5234; Part2: 1992, Annex G

No collapse of damage

Resistance to anchorage(high level wall cupboard)
eccentric downward
BS 5234; Part2: 1992, Annex K

No damage or detachment of anchor

Anchorage Load

45 kg

Acoustic performance
- 60 mm thick
- 75 mm thick
- 100 mm thick
- 120 mm thick
- 150 mm thick


38 dB
40 dB
42 dB
44 dB
46 dB



5. Installation Process



1). Setting the line and carring the board in position

2). Sawing board

3). Sizing, sizing cement mortar on the side of panels

4). Installation,  carry panel, correct panel and fix panel

5). Correcting and fixing

6). Grouting and filling starch

7). Sticking fiberglass mesh

8). installing electricity wire and switches

9). Installing doorcase

10). Facing coating and wall papers

11). Facing flexible soft ceramic tile

12). Electric apparatus installation



6. About Us



10 years production and trading experience.

40,000m2 factory area, 60000m2 stacking area.

Top 1 manufacturer in Middle of China

2,000,000m2 annual production capacity

Over 400 containers export volum per month

More than 50 countries market area
