Fast Installation EPS Building Wallboard Panels / Precast Insulated Concrete Panels

China Fast Installation EPS Building Wallboard Panels / Precast Insulated Concrete Panels supplier
Fast Installation EPS Building Wallboard Panels / Precast Insulated Concrete Panels supplier Fast Installation EPS Building Wallboard Panels / Precast Insulated Concrete Panels supplier Fast Installation EPS Building Wallboard Panels / Precast Insulated Concrete Panels supplier Fast Installation EPS Building Wallboard Panels / Precast Insulated Concrete Panels supplier

Large Image :  Fast Installation EPS Building Wallboard Panels / Precast Insulated Concrete Panels

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJWP-YRR16

Payment & Shipping Terms:

Minimum Order Quantity: 300 Square Meter
Price: negotiation
Packaging Details: Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time: 7~10 working days after receive deposit
Payment Terms: L/C,T/T,Western Union, D/A,D/P, MoneyGra
Supply Ability: 200000 Square Meters per Month
Contact Now
Detailed Product Description
Raw Material: EPS, Sand/fly Ash, Cement, Additives Specification(L*W*T): 2270*610*60/75/90/100/120/150mm
Safety: 100% Non-asbestos, Green, Eco-friendly Construction: 3 Workers One Week For 100m2 House
Fireproof: 240min (1000 Degree ) Sound Insulation: 46dB
Usage: Partition ,exterior ,roof And Floor Useful Life: 70years

 Fast Installation Light Weight EPS Precast Concrete Wall Panels Building Board



  > 1. Introduction:



Vanjoin EPS Cement Sandwich Panel are made from a non-toxic light weight core of Portland cement and expanded Polystyrene beads sandwiched between two Calcium Silicate boards. The Calcium Silicate boards used in the production are fire rated, thermal rated, water vapor resistance with excellent values.



  > 2. Composition:



Core materials: cement, EPS, and fly ash core. Surface materials: fiber reinforced calcium silicone board or cement calcium silicone board.



  > 3. Packaging & Shipping For EPS Cement Composite Panel Board:



Name

Size(L*W*T)mm

Weight (kg/m2)

Packing(pcs/m2 20’GP)

Application





EPS Cement

 sandwich
wall panel


2270x610x60

45-48

315 pcs /436 m2

Roof, interior wall

2270x610x75

50-53

252pcs / 349 m2

Interior wall

2270x610x90

55-58

207pcs / 287 m2

Interior/exterior wall

2270x610x100

60-65

189pcs / 262 m2

Interior/exterior wall

2270x610x120

65-75

153pcs / 212 m2

Exterior wall

2270x610x150

80-90

126pcs / 175 m2

Exterior wall

Remark: All kinds of panels can be customized by customers' specific requiremen



  > 4. Special Features:



Light weight

1 person can take up two pieces of vanjoin panel

Energy-saving, Eco-friendly

100% non-asbestos

Easy to install, fast construction

3 workers can finish a 70 m2 house just by 1 week

Strong and durable

Long life 60-70 years

Heat insulation and preservation

Thermal conductivity: 0.221W/mk

Sound insulation

42-46 DB

Weatherproof; windproof

70m/s; grade 13

Fireproof

keep well about 4 hours under 1000 degree temperature

Anti-impact, anti-earthquake

Grade 8

Best hanging strength

Single point hanging force is > 1200 N

Weight capacity

400KG / square meter



  > 5. Application:



Can replace construction materials as red bricks, clay solid bricks, air bricks, color-coated steel sandwich boards, gypsum blocks, wire spatial grid structure perlite boards, and perlite porous board.



- Can widely be applied to interior and exterior wall materials of various high and low buildings such as banks, office buildings, hospitals, schools, hotels, malls, amusement halls, active barracks, old houses reconstruction, residences, and workshops.



  > 6. Supply Markets:



Iran, Kazakstan, Russia, Australia, India, Dubai, South Africa, Spain, Maldives, Egypt and so on.



 > 7. Approvals & Certificates:

Vanjoin Precast EPS Concrete Sandwich Wall Panel has passed CE, , ISO9001, ISO14000, Invention Patent, STC tests, etc. We can provide free samples if you need further testing.
