Fire Rated Exterior EPS Precast Concrete Wall Panels , Heat Insulated Board

Large Image : Fire Rated Exterior EPS Precast Concrete Wall Panels , Heat Insulated Board

Product Details:

Place of Origin:	China
Brand Name:	Vanjoin
Certification:	CE, BV, ISO
Model Number:	VJWP-SW-12

Payment & Shipping Terms:

Minimum Order Quantity:	1X20 GP
Price:	negotiation
Packaging Details:	1. free package 2. standard package
Delivery Time:	7-10 working days after received advanced payment
Payment Terms:	T/T, L/C, Western Union,MoneyGram,etc.
Supply Ability:	200,000 m2 per month

Detailed Product Description

Size (LWT):	2270mmx610mmx60mm(75,60,100,120,150)	Panel Material:	Nonmetal
Application:	Exterior Wall, Interior Wall, Roof And Floor	Sound Insulation:	46dB
Fireproof:	240 Minutes – Class A	Live Load:	600kg/m2
Anti-earthquake:	8-13 Grade	Service Life:	50-60 Years
Thickness:	60,75,90,100,120,150mm	Heat Insulated:	0.07 W/m2 K

Fire Rated Exterior EPS Precast Concrete Wall Panels , Heat Insulated Board

1. Description of wall Panel

The product can replace construction materials like red brick,clay solid brick, color-coated steel sandwich board,gypsum block,wire spatial grid structure perlite board,perlite poroum board, etc.It can widely be applied to wall materials of various high and low building, such as: bank, office building, hospital, school, hotel, mall, amusement hall, active barrack, old house reconstruction, residence and workshop.

Composition

Core materials: cement, EPS, and fly ash or sand core

Surface materials: fiber reinforced calcium silicone board or cement calcium silicone board

Size and Dimension: (L*W*T)

2270mm X 610mm X60mm (75, 90,100,120,150)

2. Advantages of wall Panel

Light weight	1 person can take up two pieces of Vanjoin panel
Energy-saving, Eco-friendly	100% non-asbestos
Easy to install, fast construction	3 workers can finish a 70 m2 house just by 1 week
Strong and durable	Long life 60-70 years
Heat insulation and preservation	Thermal conductivity: 0.221W/mk
Sound insulation	42-46 DB
Weatherproof; windproof	70m/s; grade 13
Fireproof	The panel can keep well about 4 hours under 1000 degree temperature
Anti-impact, anti-earthquake	Grade 8
Best hanging strength	Single point hanging force is > 1200 N
Weight capacity	600KG / square meter

3. Comparision with other building materials

Technology index	Metal frame and plaster board	GRC Board	Gypsum block	VJ EPS Panel
Weight	20kg/m²	40kg/m²	45kg/m²	35kg/m2(60mm thickness)
Sound insulation	Almost no	normal	poor	Excellent 46dB
Waterproof	poor	normal	poor	excellent
Heat insulation	no	normal	normal	excellent
Anti-impact capacity/Hanging force	no	can impact,good hanging force	can impact,normal hanging force	High impact single hanging force 50KGS
Decoration difficulty	hard,with limiations	General difficulty	General difficulty	Easy and without any limiations
Wall thickness	91mm	60mm	75mm	60mm, increased interior space
Useful life	2-3 years	20-30 years	15-20 years	60-70 years
Material secondary use	no	some available	almost no	80% cam be used
Construction efficiency	faster	faster	faster	fast

4.Specifications of wall panel

Name	Size(LWT)mm	Weight (kg/m2)	Packing (pcs/m2 20’GP)	Application
EPS Cement Sandwich Wall Panel	2270x610x60	45-48	315 pcs /436 m2	Roof, interior wall
	2270x610x75	50-53	252pcs / 349 m2	Interior wall
	2270x610x90	55-58	207pcs / 287 m2	Interior/exterior wall
	2270x610x100	60-65	189pcs / 262 m2	Interior/exterior wall
	2270x610x120	65-75	153pcs / 212 m2	Exterior wall
	2270x610x150	80-90	126pcs / 175 m2	Exterior wall
