Insulation Cement Composite Panels, Composite Panel Board with High Hanging Strength

Large Image : Insulation Cement Composite Panels, Composite Panel Board with High Hanging Strength

Product Details:

Place of Origin:	China
Brand Name:	Vanjoin
Certification:	CE, BV, ISO
Model Number:	VJ-WP-LX026 Cement Composite Panel Board

Payment & Shipping Terms:

Minimum Order Quantity:	300m2
Price:	negotiation
Packaging Details:	Standard Exporting Packing( (wrapped with plastic thin film,wedge protect and good pallet) )
Delivery Time:	7-15 days after getting advanced payment
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Supply Ability:	4,000,000m2 per year

Detailed Product Description

Types:	Nometal Cement Composite Panel Board	Application:	Interior And Exterior Wall, Roof And Floor
Thickness:	60, 75, 90, 100, 120, 150mm	Composition:	Calcium Silicon Board, Eps Foam, Cement, Sand, Addictives
Non-combustibility:	Grade A, BS EN ISO1182:2002	Waterproof:	Good
Light Weight:	1/6 Of Traditional Brick	Fireproof:	4 Hours FRP
Anti-seismic:	7-8 Class	Heat Insulated:	Good
Fast Consruction:	50-80 M2/day	Sound Insulation:	38dB-46dB

Insulation Cement Composite Panels, Composite Panel Board with High Hanging Strength

Vanjoin lightweight compound EPS sandwich panels is a kind of energy saving light weight heat

and thermal insulation compound board. It is a new economic construction material, which can

replace red brick, clay solid brick, air brick, color-coated steel sandwich wall board, gypsum block,

wire spatial grid structure perlite board and perlite porous board.

1. Application of Cement Composite Panel Board

Our EPS Cement Sandwich Panels are widely used as interior wall and exterior wall, roof and

floor for It can be applied to various high and low rise buildings, such as hotel, officebuildings, bank,

hospital, school, shopping mall, amusement hall, portable dwellings, old house reconstruction, family

house and ect.

2. Composite of Cement Composite Panel Board
EPS cement composite panel board take 5mm Calcium Silicon Board as surface panel, with EPS (expandable polystyrene beeds), Cement, Sand, Vanjoin Patented Addictives as filler.

3. Specification of EPS Cement Composite Panel Board

Product Name	Specification (mm)	Weight (kg/m2)	Packing (pcs/m2 per 20GP)	Application
Vanjoin light weight energy-saving compound sandwich panels	2270x610x60	45~48	315pcs/436m2	Roof
	2270x610x75	50~53	252pcs/349m2	Interior wall
	2270x610x90	55~58	207pcs/287m2	Interior/Exterior wall
	2210x610x100	60~65	189pcs/262m2	Interior/Exterior wall
	2210x610x120	65~75	153pcs/212m2	Exterior wall
	2210x610x150	80~90	126pcs/175m2	Exterior wall
	2210x610x180	95~105	99pcs/138m2	Exterior wall
	Allowed Tolerance: Length±5mm; Width±2mm; Thickness±1mm; Diagonal±2mm

4. Outstanding Features of Cement Composite Panel Board

Comparing with other traditional building materials, Vanjoin composite panel board has

featurers of lightweight, fireproof, fast building, sound insulation, waterproof and space

saving. For PU panel, Our panel has best hanging force, will not rusty, more economic

and has long life span.

1) Light weight: 1/6 of traditional wall;

2) Space saving: Save 4.26m2 per 100 m2 area;

3) Water-proof, wind-proof;

4) Fireproof: 240 mins of 1000 degree fire;

5) Sound insulation 38dB-46dB, heat insulation;

6) High strength, anti-impact;

7) Anti-seismic: Class 7-8;

8) Great hanging force: Single point hanging force 50kg, Embed hanging force 150kg;

9) Fast construction: 8-10 times of traditional wall;

10) Easy decoration: convenient for pipeline embeded;

11) Eco-friendly: 100% non-asbestos

12) Recyclable and long life span: 60-70 years service life. ect.

5. Packing Size & Details of Cement Composite Panel Board

Vanjoin eps cement composit panel board take international export packing standard,

the panel will be well packed. The packing detailes is as following:

1) Free packing: with normal pallet and packing belt
2) Standard exporting packing: wrapped with plastic thin film,wedge protect and good pallet
3) Packing size: 1500-3000*610*1000mm
4) Loading: 18 pallets per 20' container

6. Photos of Cement Composite Panel Board

Cement Composite Panel Board.jpg
