High Load Bearing Fireproof Composite Panel Board for House Wall System

China High Load Bearing Fireproof Composite Panel Board for House Wall System supplier
High Load Bearing Fireproof Composite Panel Board for House Wall System supplier High Load Bearing Fireproof Composite Panel Board for House Wall System supplier High Load Bearing Fireproof Composite Panel Board for House Wall System supplier High Load Bearing Fireproof Composite Panel Board for House Wall System supplier

Large Image :  High Load Bearing Fireproof Composite Panel Board for House Wall System

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJ-WP-LX027 Composite Panel Board

Payment & Shipping Terms:

Minimum Order Quantity: 300㎡
Price: negotiation
Packaging Details: Standard Exporting Packing
Delivery Time: 7-15 days after getting advanced payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 4,000,000m2 per year
Detailed Product Description
Types: EPS Sandwich Panels Application: Interior And Exterior Wall, Roof And Floor
Thickness: 60, 75, 90, 100, 120, 150mm Sound Insulation: 38dB-46dB
Non-combustibility: Grade A, BS EN ISO1182:2002 Waterproof: Good
Light Weight: 1/6 Of Traditional Brick Fireproof: 4 Hours FRP
Anti-seismic: 7-8 Class Heat Insulated: Good

High Load Bearing Fireproof Composite Panel Board for House Wall System


Vanjoin lightweight compound EPS sandwich composite panel board is a kind of energy saving light

weight compound board. It can replace construction materials like red brick, clay solid brick, air brick,

color-coated steel sandwich wall board, gypsum block, wire spatial grid structure perlite board and

perlite porous board. This kind of composite panel board can be used as interior wall, exterior wall,

roof, floor and fence.

1. Composite of Vanjoin Fireproof Composite Panel Board

Vanjoin composite panel board consists of two main parts: surface board &core materials.



(1)Core material: EPS(Polystyrene) beads, cement, sand, water, addictives ect.

(2)Surface board: calcium silicon board 5mm, both side





2. Application of Vanjoin Fireproof Composite Panel Board

Our EPS Sandwich Wall Panels can be widely applied to varoius high and low buildings, such as bank,
office building, hotels, school, shopping mall, amusement hall, portable dwellings, warehouse, family
house, house resconstruction, workshop and ect. Vanjoin EPS Sandwich Wall Panels can used as 5
systems:Interior partition wall, Exterior wall system, Roof system, Floor system and Fence
systems.



3. Specification of Vanjoin Fireproof Composite Panel Board



Length   Width     Thickness    Weight  Application
       2270mm        610mm        60mm         45-48kg/m2                    Roof
       75mm         50-53kg/m2               Interior wall
       90mm         55-58kg/m2          Interior / Exterior wall
      100mm         60-65kg/m2          Interior / Exterior wall
      120mm         65-75kg/m2               Exterior wall
      150mm         80-90kg/m2                Exterior wall
 Allowed Tolerance: Length±5mm; Width±2mm; Thickness±1mm; Diagonal±2mm














4. Main Features of Vanjoin Fireproof Composite Panel Board
1. Light weight
The weight of Vanjoin EPS Sandwich Wall Panel is only 1/6 of traditional brick
2. Fireproof
Our sandwich panel approved fireproof test for 4 hours 1000 degree; got Grade A(GB/T9987).
3. Area-saving
Comparing with tradition building materials, for 150mm thickness wall, if using our sandwich panel, you

can save 4 m2  per 100 m2
4. Waterproof
Good waterproof perfermance. No droplets observed behind the panel, test 24 hours at 250mm water

head.
5. Sound-insulation
Excellent acoustic perfermance 38dB-46dB, 38dB for 60mm thickness panel, 46dB for 150mm thickness

panel.
6. Fast and easy construction, Labor saving
Two experienced workers installation one day, they can install 50-80 m2, which is 6 times of traditional

brick.
7. Best hanging force

Single point hanging force of our panel is 50kg, and embedded force can reach 150kg. Air conditioners,

toilet and other electricity appratus are easily installed.

8. Long life usage:70 years

5. Packing Size & Details of Vanjoin Fireproof Composite Panel Board


Length Width Thickness Packing Size of 20' GP Container
2270mm 610mm 60mm 315pcs / 436㎡
75mm 252pcs / 349㎡
90mm 207pcs / 287㎡
100mm 189pcs / 262㎡
120mm 153pcs / 212㎡
150mm 126pcs / 175㎡

Packing Details 1. Free packing with normal pallet and packing belt
2. Standard exporting packing wrapped with plastic thin film,wedge protect & good pallet
3. Packing size: 1500-3000*610*1000mm
4. Loading 18 pallets per 20' container

















6. Photos of Fireproof Composite Panel Board
Fireproof Composite Panel Board.jpg

Fireproof Composite Panel Board
Fireproof Composite Panel Board.jpg
Fireproof Composite Panel Board

Fireproof Composite Panel Board.jpg
