Product Details:
Payment & Shipping Terms:
|
| Raw Material: | EPS, Sand/fly Ash, Cement, Additives | Specification(L*W*T): | 2270*610*60/75/90/100/120/150mm |
|---|---|---|---|
| Safety: | 100% Non-asbestos, Green, Eco-friendly | Surface Panel Material: | Calcium Silicate Board |
| Fireproof: | 240min (1000 Degree ) | Sound Insulation: | 46dB |
| Anti-earthquake: | Class 8-13 | Useful Life: | 70years |
120mm Heat Insulated EPS Pracast Concrete Wall Panels Anti Seismic Panels
Composition:
Core materials: cement, EPS, and fly ash or sand core
Surface materials: fiber reinforced calcium silicone board or cement calcium silicone board
Panel Specification:
Name | Size(L*W*T)mm | Weight (kg/m2) | Packing(pcs/m2 20’GP) | Application |
| 2270x610x60 | 45-48 | 315 pcs /436 m2 | Roof, interior wall |
2270x610x75 | 50-53 | 252pcs / 349 m2 | Interior wall | |
2270x610x90 | 55-58 | 207pcs / 287 m2 | Interior/exterior wall | |
2270x610x100 | 60-65 | 189pcs / 262 m2 | Interior/exterior wall | |
2270x610x120 | 65-75 | 153pcs / 212 m2 | Exterior wall | |
2270x610x150 | 80-90 | 126pcs / 175 m2 | Exterior wall |
Remark: All kinds of panels can be customized by customers' specific requirement,
Wall Panel Performance:
Light weight | 1 person can take up two pieces of vanjoin panel |
Energy-saving, Eco-friendly | 100% non-asbestos |
Strong and durable | Long life 60-70 years |
Heat insulation and preservation | Thermal conductivity: 0.221W/mk |
Sound insulation | 42-46 DB |
Weatherproof; windproof | 70m/s; grade 13 |
Fireproof | Our sandwich wall panel can keep well under 1000 degree |
Anti-impact, anti-earthquake | Grade 8 |
Best hanging strength | Single point hanging force is > 1200 N |
Load bearing capacity | Over 50 kg |
Application of EPS Wall Panel:
1) Floor System
Vanjoin light weight compound sandwich panel can be innovatively used as floor board. This system has the outstanding advantages such as high load-bearing capacity, anti-static electricity, friction resistance, high strength, convenient for wire groove and water pipe inbuilt, corrosion resistance, no deformation, no split, etc.
2) Roof System
This system not only solves the problem of roof leakage, but also has the advantages such as heat insulation, neat joint surface, high temperature resistance, etc.
3) Interior Partition System
With EXCELLENT fireproof, best hanging force, sound insulation, heat insulation, waterproof, easy installation and the like characteristics.
4) Interior & Exterior Wall System
Vanjoin lightweigh compound sandwich panel can automatically adjust indoor air and water content with the season and climate changes, which can keep the temperature at an invariable temperature level, and such ecology effect just goes with the tide of modern residential building. It is widely applied to various modular house, low buildings, apartment, villas, and city house, etc.
Panel Types:
Different Types | Different Panels |
Type 1 | EPS cement sandwich panel |
Type 2 | Solid eps cement sandwich panel |
Type 3 | Ceramisite sandwich panel |
Type 4 | Solid Ceramisite sandwich panel |
Type 5 | Perlite sandwich panel |
Type 6 | Solid perlite sandwich panel |
Type 7 | Eps & Ceramicite Sandwich Panel |
Type 8 | Solid Eps & Ceramicite Sandwich Panel |
About US:
We are experienced in this field for 10 years;
We have a 40,000m2 factory, with 60000m2 sotcking area;
We are ranking Top 2 in China, and Top 1 in middle of China;
We are certificated with CE, , ISO9001, ISO14000, Invention Patent, STC tests, etc;
Our production capacity is 2,000,000m2/year;
Our average exports is over 400 containers/month;
Our main markets: Southeast Asia, Africa, Middle East, South America, Oceania, Europe, etc.
