100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels

Certification
Good quality EPS Cement Sandwich Panel for sales
Good quality EPS Cement Sandwich Panel for sales
Customer Reviews
I thought no body cares about others any more,but you changed this.

鈥斺 Mana AI Yaseen,Saudi Arabia

I appreciate very much your very kind attention to may request and it give to me a very strong confidence in your company in your services

鈥斺 Alfredo Friedmann,Paraguay

You are so kind and good service.

鈥斺 Samuel,Indonesia

You are star.I want to be your friend

鈥斺 Gert,South Africa

I'm Online Chat Now

100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels

China 100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels supplier
100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels supplier 100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels supplier 100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels supplier 100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels supplier

Large Image :  100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJ-WPE-02H

Payment & Shipping Terms:

Minimum Order Quantity: 300 Square Maters
Price: negotiation
Packaging Details: 1. Free packing ( with normal pallet and normal packing belt ) 2. Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time: 7~15 working days after receive payments
Payment Terms: L/C,T/T,Western Union
Supply Ability: 200000 Square Meters per Month
Contact Now
Detailed Product Description
Product Name: Sandwich Wall Panels Core Material: EPS, Cement, Sand, Water, Additive, Etc
Specification: 2270*610*100mm Usage: Exterior And Interior Wall, Floor
Color: Grey Acoustic Performance: 42dB
Weight: 60-65kg/銕 Flexural Strength: 4.27MPa

100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels


Brief Introduction:



The sandwich wall panel can replace construction material like red brick, clay solid brick, air brick, color-coated steel sandwich board, gypsum block, wire spatial grid structure perlite board, perlite porous board etc.

It can be widely applied to various high and low buildings such as: bank, office, building, hospital, school, hotel, shopping mall, amusement hall, portable dwellings, old house reconstruction, family house and workshop.



 Advantages of Vanjoin Sandwich panel:



Light weight: 1 person can take up two pieces of vanjoin panel.

Energy-saving, Eco-friendly: 100% non-asbestos.

Easy to install, fast construction: Can build 75-80銕 per day.

Strong and durable: Long life 60-70 years.

Heat insulation and preservation: Thermal conductivity: 0.221W/mk.

Sound insulation: 42 DB.

Weatherproof; windproof: 70m/s; grade 13.

Fireproof: Our sandwich wall panel can keep well under 1000 degree temperature about 4 hours.

Anti-impact, anti-earthquake: Grade 8.

Best hanging strength : Single point hanging force is > 1200 N.

Weight capacity: 400KG / square meter.

Package: 189 pcs, 262 銕 per 20'ft container.



Technology Index:





Item

National Standards

Testing Indexes



Thickness

60mm

90mm

120mm

60mm

90mm

120mm

1

Anti-impact Capacity/times

≥5

≥5

≥5

≥8

≥10

≥15

2

Anti-bending damage load/times over deadweight

≥1.5

≥1.5

≥1.5

≥3

≥4

≥5

3

Compressive strength /Mpa

≥3.5

≥3.5

≥3.5

≥5

≥5

≥5

4

Softening coefficient

≥0.80

≥0.80

≥0.80

≥1

≥1

≥1

5

Surface density g/m2

≤70

≤90

≤110

≤55

≤70

≤85

6

Moisture rate  a/%

≤12/10/8

≤10/9/7

7

Drying shrinkage value /mm/m

≤0.6

≤0.6

≤0.6

≤0.45

≤.0.5

≤0.5

8

Hanging Force/N

≥1000

≥1000

≥1000

≥1200

≥1300

≥1500

9

Sound insulation capacity in the air /Db

≥30

≥35

≥40

≥35

≥40

≥45

10

Fire proof limit /h

≥1

≥1

≥1

≥2.5

≥3

≥4

11

Heat transfer coefficient  w/m2.k





≤1.0





≤1.0

12

Radioactivity Limit

≤1

≤1

≤1

≤1

≤1

≤1

13

IRa (Inner radiation indexes)

≤1

≤1

≤1

≤1

≤1

≤1

14

Ir (Outer radiation indexes)

≤1

≤1

≤1

≤1

≤1

≤1



Sandwich Wall Panels:



100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels

100mm Tongue And Groove Heat Insulation SIP Sandwich Wall Panels
