100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall

Certification
Good quality EPS Cement Sandwich Panel for sales
Good quality EPS Cement Sandwich Panel for sales
Customer Reviews
I thought no body cares about others any more,but you changed this.

鈥斺 Mana AI Yaseen,Saudi Arabia

I appreciate very much your very kind attention to may request and it give to me a very strong confidence in your company in your services

鈥斺 Alfredo Friedmann,Paraguay

You are so kind and good service.

鈥斺 Samuel,Indonesia

You are star.I want to be your friend

鈥斺 Gert,South Africa

I'm Online Chat Now

100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall

China 100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall supplier
100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall supplier 100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall supplier 100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall supplier 100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall supplier

Large Image :  100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJ-WPE-01

Payment & Shipping Terms:

Minimum Order Quantity: 1X20GP Container free sample available
Price: negotiation
Packaging Details: 1. Free packing ( with normal pallet and normal packing belt ) 2. Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time: 7~10 working days after receive payments
Payment Terms: L/C,T/T,Western Union, D/A,D/P, MoneyGra
Supply Ability: 200000 Square Meter/Square Meters per Mont
Contact Now
Detailed Product Description
Product Name: Sandwich Wall Panels Core Material: EPS, Cement, Sand, Water, Additive, Etc
Specification(L*W*T): 2270*610*60/75/90/100/120/150mm Surface Panel: Alicium Silicon Board
Advantages: Waterproof, Fireproof, Sound Insulation, Heat Insulation Panel Fireproof: Under 1000 Degree For 4 Hours Without Damage To The Wall
Service Life: 60-70 Years Anti-earthquake: Class 8
Thermal Conductivity: 0.221W/mK

 100MM Lightweight Fast Construction Eps Cement Sandwich Wall Panels for Interior Wall

> 1. Composition of Sandwich Wall Panels:


Core materialscement, EPS, sand and additives.
Surface materialsfiber reinforced calcium silicate board or cement calcium silicate Board.



> 2. Specification of Sandwich Wall Panels:
• Thickness: 60, 75, 90, 100, 120, 150mm
• Width: 610mm
• Length: 2270mm (custom-made length can be made for volumn order)
100MM Lightweight Eps Cement Sandwich Wall Panels for Interior Wall
 Remark: All kinds of panels can be customized by customers' specific requirement,
 such as density and length of panel.

> 3. Features and Advantages of Sandwich Wall Panels:

Interior/Exterior
Sandwich Panel

Fast construction

75-80m2/day three workman

Sound insulation

46dB

Space saving

Save 4.26m2 per 100 m2 area

Anti-seismic

Class 7-8

Fireproof

4 hours, under 1000 degree centigrade

Eco-friendly

100% non-asbestos

Hanging force

Single point hanging force 50kg, Embed hanging force 150kg

Service Life

60-70years



> 4. Installation of Sandwich Wall Panels:


1. Setting the line and carrying
the board in position

Eject double lines of board thickness up and down the axes
of installed wall board, and easily carry to the side of wall
according to the specification needed;

2. Sawing board

Using hand-hold electric saw to cut freely according to the
 wall specification.

3. Sizing

Sizing cement on tenon side of two boards, then  spread
polymer mortar on the tenon side casually;

4. Installation

Carrying the board prepared to be installed to the
installation place, correcting the wall board by
gavelock and making it close tightly, and let the
polymer mortar squeeze out into full and fixing
it with a chock temporarily;

5. Correcting, fixing

Using the guiding rule of two meters to check the
verticality and leveling correction. Then using 6mm
or 8mm reinforcing steel bar and ribs adding with
construction sealant to fix;

6. Grouting and filling starch

Filling the strickling the corrected wall board with
polymer mortar, filling the big gap with pea gravel
concrete;

7. Sticking fiberglass mesh (we can supply )

After the polymer (for filling the gaps) and Wall are
shaped, sticking fiberglass mesh on the whole wall
with anti-crack mortar.

8. Installing electrical wires and switches

Setting lines on the places needing to be set with
concealed wire and switch box, then cut a groove
by hand-hold electric saw, filling with polymer mortar
after installation

9. Installing doorcase

Preparing door and window holes on the installed wall,
anchoraging by splint or lines.

10. Facing coating and wall papers

Scraping putty directly without plastering on the installed
wall, then brushing coating and sticking wall paper

11. Facing ceramic tile,decorative sheet

Sticking ceramic tiles or other wood facing panels
casually without plastering on installed wall.

12. Electric apparatus installation

Install lights, furniture, air-conditioners casually on
installed room ,can be nailed or hanged




> 5. RFQ of Sandwich Wall Panels:



1 : How many years your company have been in this field?
Ans: More than 10 years of manufacturing Lightweight Sound Insualtion Precast Concrete Panels, now we are the TOP 3 in middle of China, and among TOP 3 in China in this field.


2 : Main market of Vanjoin ?
Ans: Main market : Asia, South Amercia, Africa
         South East Asia is our largest market ,Mid East is our second largest market


3 : Exporting details :
Ans: loading & shipping 400 20ft every month


4 : More information of Vanjoin factory ?
Ans: Land area: 30,000m2 Machines: Fully automatic production line
         Productivity: 2,000,000m2 wall panel every year.


5 : How could I get the samples ?
Ans: We send you the free Lightweight Sound Insualtion Precast Concrete Panels samples, brochures & installation cd etc, you pay for the freight charges. If you get the TNT, DHL, UPS  Fedex account, that is the best. If not, you can transfer money to our West Union account , then we send you Lightweight Sound Insualtion Precast Concrete Panels samples by Vanjoin account.
