Precast Concrete Heat Insulation Sandwich Panel for Interior and Exterior Wall

China Precast Concrete Heat Insulation Sandwich Panel for Interior and Exterior Wall supplier
Precast Concrete Heat Insulation Sandwich Panel for Interior and Exterior Wall supplier Precast Concrete Heat Insulation Sandwich Panel for Interior and Exterior Wall supplier Precast Concrete Heat Insulation Sandwich Panel for Interior and Exterior Wall supplier Precast Concrete Heat Insulation Sandwich Panel for Interior and Exterior Wall supplier

Large Image :  Precast Concrete Heat Insulation Sandwich Panel for Interior and Exterior Wall

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJ-WP-AY007

Payment & Shipping Terms:

Minimum Order Quantity: 300m2
Price: negotiation
Packaging Details: Standard Exporting Pallet Packing, 18 Pallets per 20ft Container
Delivery Time: 7 Working Days
Payment Terms: T/T, L/C
Supply Ability: 200,000m2 per Month
Contact Now
Detailed Product Description
Features: Lightweight, Waterproof Panel Type: Non-metal Panel
Usage: Mainly For Interior And Exterior Wall Application 1: Villa, Residential House, Granny Flat Home
Application 2: School, Shopping Mall, Hospital Single Point Hanging Force: 50kg
Advantages: Green, Without Asbestos, Durable, Long Lifespan Minimum Thickness: 60mm
Maximum Thickness: 150mm Length: 2270mm
Width: 610mm

Light Weight Precast Concrete Wall Panels Heat Insulation Sandwich Panel



1. Composition



Face board  Both sides are calcium silicate board
Core materials  eps foam, cement, sand, additives



2. Application



Low house Residential house,villa, granny flat home, shop,etc
High Building Office, shopping mall, school, hospital,etc



3. Advantages


Lightweight

1 person can carry panel easily

Eco-friendly

100% non-asbestos

Fast Construction

3 workers can install 60-80m2 per day

Strong,Durable and Long Lifespan

70 years

Sound Insulation

42-46 dB

Windproof

65m/s

Fireproof

4 hours

Anti-earthquake

Grade 8-9

Best hanging force

Single point hanging force is 50kg

Weight capacity

650KG / square meter



 4. Performance



Flexural Strength(longitudianal)

4.27 MPa

Flexural Strength(transverse)

4118N

Moisture Movement

0.06%

Moisture Content

9%

Resistance to continuous heating

80 °c

Surface Alkalinity

pH 7-10

Non-combustibility(face Boards)

BS EN ISO 1182: 2002
BS476: Part 4
GB8624-1997, Grade A

Heat of combustion(face boards)

BS EN ISO 1716: 2002

Building regulations classification(face boars)

Euro Class A1

Fire rated partition

2 hour FRP
BS EN 1364-1
BS 476: Part 22
GB/T9978

Water tightness to ASTM C1185

No droplets observed behind the panel,
Test of 24 hours at 250 mm water head

Partition stiffness-heavy duty grade
(BS 5234; Part2: 1992, Annex A)

Pass

Resistance to substructure damage by multiple impacts
from a large soft body
-heavy duty grade( BS 5234; Part2: 1992, Annex E)

No collapse of dislocation

Surface damage by hard body impact- heavy duty grade
(BS 5234; Part2: 1992, Annex B)

Pass

Effects of door slamming-heavy duty grade
BS 5234; Part2: 1992, Annex B

Pass

resistance to crowd pressure-heavy duty grade
BS 5234; Part2: 1992, Annex G

No collapse of damage

Resistance to anchorage(high level wall cupboard)
eccentric downward
BS 5234; Part2: 1992, Annex K

No damage or detachment of anchor

Anchorage Load

45 kg

Acoustic performance
- 60 mm thick
- 75 mm thick
- 100 mm thick
- 120 mm thick
- 150 mm thick


38 dB
40 dB
42 dB
44 dB
46 dB



5. Installation Tools



Electrical cutter

Electrical hammer

Trowel

Level instrument

Level ruler

Measuring tape

Hammer



6. Installation Accessories



Cement mortar, connecting wall panels

Steel bar, fix wall panels

Fiberglass mesh, base layer for wall anti-cracking

Anti-crack mortar, basic adhesive for wall anti-cracking



7. Installation Process



1). Setting the line and carring the board in position

2). Sawing board

3). Sizing, sizing cement mortar on the side of panels

4). Installation,  carry panel, correct panel and fix panel

5). Correcting and fixing

6). Grouting and filling starch

7). Sticking fiberglass mesh

8). installing electricity wire and switches

9). Installing doorcase

10). Facing coating and wall papers

11). Facing flexible soft ceramic tile

12). Electric apparatus installation



8. Company Information



We are a manufacturing and trading combo for lightweight sandwich wall panels in Wuhan China,
with 10 years full experience and a professional sales team.
We have exported our sandwich wall panels to over 50 countries, with high quality and moderate price.



9About Us

10 years production and trading experience.
40,000m2 factory area, 60000m2 stacking area.
Top 1 manufacturer in Middle of China
2,000,000m2 annual production capacity
Over 400 containers export volum per month
More than 50 countries market area
