Eco Friendly Insulated Sandwich Panel For European Style Villa Home

Large Image : Eco Friendly Insulated Sandwich Panel For European Style Villa Home

Product Details:

Place of Origin:	China
Brand Name:	Vanjoin
Certification:	CE, BV, ISO
Model Number:	VJ-WPE-03H

Payment & Shipping Terms:

Minimum Order Quantity:	300 Square Maters
Price:	negotiation
Packaging Details:	1. Free packing ( with normal pallet and normal packing belt ) 2. Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time:	7~15 working days after receive payments
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	200000 Square Meters per Month

Detailed Product Description

Product Name:	Sandwich Wall Panels	Raw Material:	EPS, Cement, Sand, Water, Additive, Etc
Specifications:	2270*610mm	Thickness:	60mm, 75mm, 90mm, 100mm, 120mm, 150mm
Apply For:	Exterior And Interior Wall, Floor	Acoustic Performance:	38-46dB
Weight:	45-90kg/㎡	Non-combustibility:	Grade A

Eco-friendly Insulated Sandwich Wall Panel For European Style Villa Home

Eco Friendly Insulated Sandwich Panel For European Style Villa Home
1. Brief Introduction of Vanjoin Sandwich panel:

The sandwich wall panel can replace construction material like red brick, clay solid brick, air brick, color-coated steel sandwich board, gypsum block, wire spatial grid structure perlite board, perlite porous board etc.

It can be widely applied to various high and low buildings such as: bank, office, building, hospital, school, hotel, shopping mall, amusement hall, portable dwellings, old house reconstruction, family house and workshop.

2. Advantages of Vanjoin Sandwich panel:

※ Light weight: 1 person can take up two pieces of vanjoin panel.

※ Energy-saving, Eco-friendly: 100% non-asbestos.

※ Easy to install, fast construction: Can build 75-80㎡ per day.

※ Strong and durable: Long life 60-70 years.

※ Heat insulation and preservation: Thermal conductivity: 0.221W/mk.

※ Sound insulation: 42 DB.

※ Weatherproof; windproof: 70m/s; grade 13.

※ Fireproof: Our sandwich wall panel can keep well under 1000 degree temperature about 4 hours.

※ Anti-impact, anti-earthquake: Grade 8.

※ Best hanging strength : Single point hanging force is > 1200 N.

※ Weight capacity: 400KG / square meter.

※ Package: 189 pcs, 262 ㎡ per 20'ft container.

3. Technology Index of Vanjoin Sandwich panel:

	Item	National Standards			Testing Indexes
	Thickness	60mm	90mm	120mm	60mm	90mm	120mm
1	Anti-impact Capacity/times	≥5	≥5	≥5	≥8	≥10	≥15
2	Anti-bending damage load/times over deadweight	≥1.5	≥1.5	≥1.5	≥3	≥4	≥5
3	Compressive strength /Mpa	≥3.5	≥3.5	≥3.5	≥5	≥5	≥5
4	Softening coefficient	≥0.80	≥0.80	≥0.80	≥1	≥1	≥1
5	Surface density g/m2	≤70	≤90	≤110	≤55	≤70	≤85
6	Moisture rate a/%	≤12/10/8			≤10/9/7
7	Drying shrinkage value /mm/m	≤0.6	≤0.6	≤0.6	≤0.45	≤.0.5	≤0.5
8	Hanging Force/N	≥1000	≥1000	≥1000	≥1200	≥1300	≥1500
9	Sound insulation capacity in the air /Db	≥30	≥35	≥40	≥35	≥40	≥45
10	Fire proof limit /h	≥1	≥1	≥1	≥2.5	≥3	≥4
11	Heat transfer coefficient w/m2.k			≤1.0			≤1.0
12	Radioactivity Limit	≤1	≤1	≤1	≤1	≤1	≤1
13	IRa (Inner radiation indexes)	≤1	≤1	≤1	≤1	≤1	≤1
14	Ir (Outer radiation indexes)	≤1	≤1	≤1	≤1	≤1	≤1

4. Application of Vanjoin Sandwich panel:

For interior and exterior wall partition on steel or concrete structure building, new construction or renovations. It can replace construction materials such as block, wire spatial grid structure perlite board, perlite porous board and etc. It can widely be applied to wall materials of various high and low buildings such as bank, office building, hospital, school, hotel, mall, amusement, old house reconstruction, residence and workshop.

Eco Friendly Insulated Sandwich Panel For European Style Villa Home

5. Compared with Metal frame and plaster board:

Technology index	Vanjoin sandwich wall panel	Metal frame and plaster board
Weight	35kg/m2(60mm thickness)	20kg/m2
Sound insulation	excellent,46dB	Almost no
Waterproof	excellent	poor
Heat insulation	excellent	no
Anti-impact capacity/Hanging force	high impact single hanging force is over 50KGS	no
Decoration difficulty	easy and without any limiations	hard,with limiations
Wall thickness	60mm,increased interior space	91mm
Useful life	60-70 years	2-3 years
Material secondary use	80% can be used	no
Construction efficiency	fast	faster
Time and labor cost	Low	High
