Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface

China Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface supplier
Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface supplier Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface supplier Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface supplier Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface supplier

Large Image :  Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJ-WPE-P03H

Payment & Shipping Terms:

Minimum Order Quantity: 300 Square Maters
Price: negotiation
Packaging Details: 1. Free packing ( with normal pallet and normal packing belt ) 2. Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time: 7~15 working days after receive payments
Payment Terms: L/C,T/T,Western Union
Supply Ability: 200000 Square Meters per Month
Detailed Product Description
Product Name: Precast Concrete Wall Panels Raw Materials: EPS, Cement, Sand, Water, Additives, Etc
Surface Board: Calcium Silicate Board Density: 650kg/m³
Construction Efficient: 75-80 SQM / Day Fire Resistance: Four Hours Under 1000 Degrees Centigrade
Anti-earthquake: Class 8 Eco-friendly: Absolutely Non-asbestos

Hight Efficient Construction High Density Precast Concrete Wall Panels



Advantages:



1 . Most energy-saving, light weight, environmental protection

The capacity is 650kg/m³, just sixth of the brick building



2 . Most Area-saving

In comparison of the inner wall panel 75mm abd 120mm, every 12m will increase practical area, for the 100㎡ house, it will increase 4.26㎡.



3 . Most waterproof and dampproof

Because of the special featuresof the solid panel, the feature of waterproof and dampproof is very obvious. The experiment shows that without any waterproof facing, build one pool with our products, and fill it with water, the back of the wall can keep dry without ant blot.When in damp weather, there isn't any condensation wate.



4 . Most fire-proof

Under 1000 degree centigrade for 240 minutes, there isn't damage to the wall.



5 . Most sound-insulation

46dB-50dB sound-insulation effect, accord with the national standard GBJ121-88.



6 . Most anti-seismic and inpact resistance

Earthquake resistant level: M8.0



7 . Most civilized, environmental, high efficiency construction

Simple construction and transportation, stacking health, dry operation, no sludge, low loss, less waste, construction convenient, no bricklaying plastering, shorten the construction period, slotted fast, easy to install water and electricity pipeline. The construction efficiency is 8-10 times of the normal masonry, it's a kind of high-quality reusable wall.



Application:



1. Floor System

Vanjoin Precast Concrete Wall Panel can be innovatively used as floor board. This system has the outstanding advantages such as high load-bearing capacity, anti-static electricity, friction resistance, high strength, convenient for wire groove and water pipe inbuilt, corrosion resistance, no deformation, no split, etc.



2. Roof System

This system not only solves the problem of roof leakage, but also has the advantages such as heat insulation, neat joint surface, high temperature resistance, etc.



3. Interior Partition System

With EXCELLENT fireproof, best hanging force, sound insulation, heat insulation, waterproof, easy installation and the like characteristics.



4. Interior & Exterior Wall System

Vanjoin Precast Concrete Wall Panels can automatically adjust indoor air and water content with the season and climate changes, which can keep the temperature at an invariable temperature level, and such ecology effect just goes with the tide of modern residential building. It is widely applied to various modular house, low buildings, apartment, villas, and city house, etc.



Specifications And Packing:



Name

Specification

(mm)

Weight

(kg/m2)

Packing

(pcs and m2 per 20' FCL)

Precast Concrete Wall Panels

2270x610x60

45~48

315pcs, 436m2



2270x610x75

50~53

252pcs, 349m2



2270x610x90

55~58

207pcs, 287m2



2270x610x100

60~65

189pcs, 262m2



2270x610x120

65~75

153pcs, 212m2



2270x610x150

80~90

126pcs, 175m2



Technical Datas:



Moisture Content

9%

Moisture Movement

0.06%

Resistance to Continuous Heating

80°C

Surface Alkalinity

pH 7-10

Non-combustibility(face board)

BS EN ISO 1182: 2002

BS476: Part 4

GB8624-1997, Grade A

Building Regulations Classification(face board)

Eur0 Class A1

Fire Rated Partition

4 hour FRP

BS EN 1364-1

BS 476: Part 22

GB/T9978

Anchorage

45kg

Acoustic Performance

-60mm thick

-75mm thick

-100mm thick

-120mm thick

-150mm thick



38dB

40dB

42dB

44dB

46dB



Precast Concrete Wall Panels:



Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface

Construction High Density Precast Concrete Wall Panels Calcium Silicate Board Surface
