Fast Installation Durable Precast Insulated Concrete Wall Panels High Story Project

Large Image : Fast Installation Durable Precast Insulated Concrete Wall Panels High Story Project

Product Details:

Place of Origin:	China
Brand Name:	Vanjoin
Certification:	CE, BV, ISO
Model Number:	VJ-WL-WP-103

Payment & Shipping Terms:

Minimum Order Quantity:	1X20GP Container free sample available
Price:	negotiation
Packaging Details:	1. Free packing ( with normal pallet and normal packing belt ) 2. Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time:	7~10 working days after receive payments
Payment Terms:	L/C,T/T,Western Union, D/A,D/P, MoneyGra
Supply Ability:	200000 Square Meter/Square Meters per Mont

Detailed Product Description

Soundproof Nonmetal Concrete Eps Sandwich Wall Panels Flat Apartment Building:	Nonmetal Panel	Length:	2270mm,2440mm,2700mm,3000mm
Width:	610mm	Thickness:	60mm,75mm,90mm,100mm,120mm,150mm
Fireproof:	240 Minutes Under 1000 Degree	Application:	Internal Wall , External Wall , Roof , Floor
Hanging Force:	More Than 50KG	Feathures 1:	Waterproof , Lightweight ,Energy Saving
Feathures 2:	Fire Resistant , Eco-Friendly , Fast Installation	Features 3:	Space Saving , Save Labor Cost,Heat Insulation

Fast Installation Durable Insulated Precast Concrete Wall Panels High Project

1. Specification: (L*W*T)

1500-3000mm X 610mm X (60, 90,120,150,180mm)

2. Sandwich wall panel Composition :

3. Application

Vanjoin Wall Panel can replace

many construction materials

Replacing such as red brick, clay solid brick, air brick;

Apply to various high and low buildings such as bank, office building,

hospital, school, hotel, supermarket, amusement hall, active barrack,

old houses reconstruction, residence, and workshop, etc.

Application

Exterior & Interior wall system, Roof system, Floor system

Fast Installation Durable Precast Insulated Concrete Wall Panels High Story Project

4.Technology Index:

	Item	National Standards			Testing Indexes
	Thickness	60mm	90mm	120mm	60mm	90mm	120mm
1	Anti-impact Capacity/times	≥5	≥5	≥5	≥8	≥10	≥15
2	Anti-bending damage load/times over deadweight	≥1.5	≥1.5	≥1.5	≥3	≥4	≥5
3	Compressive strength /Mpa	≥3.5	≥3.5	≥3.5	≥5	≥5	≥5
4	Softening coefficient	≥0.80	≥0.80	≥0.80	≥1	≥1	≥1
5	Surface density g/m2	≤70	≤90	≤110	≤55	≤70	≤85
6	Moisture rate a/%	≤12/10/8			≤10/9/7
7	Drying shrinkage value /mm/m	≤0.6	≤0.6	≤0.6	≤0.45	≤.0.5	≤0.5
8	Hanging Force/N	≥1000	≥1000	≥1000	≥1200	≥1300	≥1500
9	Sound insulation capacity in the air /Db	≥30	≥35	≥40	≥35	≥40	≥45
10	Fire proof limit /h	≥1	≥1	≥1	≥2.5	≥3	≥4
11	Heat transfer coefficient w/m2.k			≤1.0			≤1.0
12	Radioactivity Limit	≤1	≤1	≤1	≤1	≤1	≤1
13	IRa (Inner radiation indexes)	≤1	≤1	≤1	≤1	≤1	≤1
14	Ir (Outer radiation indexes)	≤1	≤1	≤1	≤1	≤1	≤1
