Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings

China Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings supplier
Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings supplier Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings supplier Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings supplier Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings supplier

Large Image :  Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJ-WPE-P06H

Payment & Shipping Terms:

Minimum Order Quantity: 300 Square Maters
Price: negotiation
Packaging Details: 1. Free packing ( with normal pallet and normal packing belt ) 2. Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time: 7~15 working days after receive payments
Payment Terms: L/C,T/T,Western Union
Supply Ability: 200000 Square Meters per Month
Contact Now
Detailed Product Description
Product Name: Fireproof Lightweight Wall Panels For Steel Structure Buildings Raw Materials: EPS, Cement, Sand, Water
Surface Board: Calcium Silicate Board , Fiber Cement Board Density: 650KG / M2
Construction Efficient: 75-80 SQM Per Day Fire Resistance: 4 Hours
Samples: Provided For Free Eco-friendly: Non-asbestos



Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings



Advantages:



1 . Most energy-saving, light weight, environmental protection

The capacity is 650kg/m³, just sixth of the brick building



2 . Most Area-saving

In comparison of the inner wall panel 75mm abd 120mm, every 12m will increase practical area,

for the 100銕 house, it will increase 4.26銕.



3 . Most waterproof and dampproof

Because of the special featuresof the solid panel, the feature of waterproof and dampproof is very

obvious. The experiment shows that without any waterproof facing, build one pool with our products,

and fill it with water, the back of the wall can keep dry without ant blot.When in damp weather, there

isn't any condensation wate.



4 . Most fire-proof

Under 1000 degree centigrade for 240 minutes, there isn't damage to the wall.



5 . Most sound-insulation

46dB-50dB sound-insulation effect, accord with the national standard GBJ121-88.



6 . Most anti-seismic and inpact resistance

Earthquake resistant level: M8.0



7 . Most civilized, environmental, high efficiency construction

Simple construction and transportation, stacking health, dry operation, no sludge, low loss, less waste,

construction convenient, no bricklaying plastering, shorten the construction period, slotted fast,

easy to install water and electricity pipeline. The construction efficiency is 8-10 times of the normal

masonry, it's a kind of high-quality reusable wall.



Application:



Vanjoin Precast Concrete Wall Panels can apply to interior wall, exterior wall, roof, floor, replacing construction materials as red bricks, clay solid bricks, air bricks, color-coated steel sandwich boards, gypsum blocks, wire spatial grid structure perlite boards, and perlite porous board.


Vanjoin Precast Concrete Wall Panels has been widely be applied to wall materials of various high and low buildings such as banks, office buildings, hospitals, schools, hotels, malls, amusement halls, active barracks, old houses reconstruction, residences, and workshops



1. Floor System

Vanjoin Precast Concrete Wall Panel can be innovatively used as floor board. This system has the outstanding advantages such as high load-bearing capacity, anti-static electricity, friction resistance, high strength, convenient for wire groove and water pipe inbuilt, corrosion resistance, no deformation, no split, etc.



2. Roof System

This system not only solves the problem of roof leakage, but also has the advantages such as heat insulation, neat joint surface, high temperature resistance, etc.



3. Interior Partition System

With EXCELLENT fireproof, best hanging force, sound insulation, heat insulation, waterproof, easy installation and the like characteristics.



4. Interior & Exterior Wall System

Vanjoin Precast Concrete Wall Panels can automatically adjust indoor air and water content with the season and climate changes, which can keep the temperature at an invariable temperature level, and such ecology effect just goes with the tide of modern residential building. It is widely applied to various modular house, low buildings, apartment, villas, and city house, etc.



Specifications And Packing:



Specification

(mm)

Weight

(kg/m2)

Packing

(pcs and m2 per 20' FCL)

2270x610x60

45~48

315pcs, 436m2

2270x610x75

50~53

252pcs, 349m2

2270x610x90

55~58

207pcs, 287m2

2270x610x100

60~65

189pcs, 262m2

2270x610x120

65~75

153pcs, 212m2

2270x610x150

80~90

126pcs, 175m2



Technical Datas:



Moisture Content

9%

Moisture Movement

0.06%

Resistance to Continuous Heating

80°C

Surface Alkalinity

pH 7-10

Non-combustibility(face board)

BS EN ISO 1182: 2002

BS476: Part 4

GB8624-1997, Grade A

Building Regulations Classification(face board)

Eur0 Class A1

Fire Rated Partition

4 hour FRP

BS EN 1364-1

BS 476: Part 22

GB/T9978

Anchorage

45kg

Acoustic Performance

-60mm thick

-75mm thick

-100mm thick

-120mm thick

-150mm thick



48dB

50dB

52dB

54dB

56dB



Lightweight Wall Panel:

Windproof Strong Precast Concrete Wall Panels For Steel Structure Buildings
