Windproof precast insulated concrete panels With Calcium Silicated Boards

China Windproof precast insulated concrete panels With Calcium Silicated Boards supplier
Windproof precast insulated concrete panels With Calcium Silicated Boards supplier Windproof precast insulated concrete panels With Calcium Silicated Boards supplier Windproof precast insulated concrete panels With Calcium Silicated Boards supplier Windproof precast insulated concrete panels With Calcium Silicated Boards supplier

Large Image :  Windproof precast insulated concrete panels With Calcium Silicated Boards

Product Details:

Place of Origin: China
Brand Name: Vanjoin
Certification: CE, BV, ISO
Model Number: VJWP-YRR83

Payment & Shipping Terms:

Minimum Order Quantity: 300 Square Meter
Price: negotiation
Packaging Details: 1. Free packing ( with normal pallet and normal packing belt ) 2. Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time: 7~10 working days after receive deposit
Payment Terms: L/C,T/T,Western Union, D/A,D/P, MoneyGra
Supply Ability: 200000 Square Meters per Month
Contact Now
Detailed Product Description
Product Name: Cement Sandwich Panel Non-combustibility: Grade A, BS EN ISO1182:2002
Safety: 100% Non-asbestos, Green, Eco-friendly Raw Material: Sand,cement,fly Ash,additive
Fireproof: 240min (1000 Degree ) Anchorage Load: 150 Kgs
Anti-wind: 13 Degree Usage: Interior Partition ,exterior ,roof And Floor



Windproof precast insulated concrete panels With Calcium Silicated Boards

Green Raw Materials:


- Surface: calcium silicate board
- Core: eps, cement, sand, water, additives,etc.

Panel Specification:



Name

Size(L*W*T)

Weight(KG)

Packing(pcs/銕 per 20")

VJ light weight compound
sandwich panel

2270*610*60

45-48

315 pcs / 436 銕

2270*610*75

50-53

252 pcs / 349 銕

2270*610*90

55-58

207 pcs / 287 銕

2270*610*100

60-65

189 pcs / 262 銕

2270*610*120

65-75

153 pcs / 212 銕

2270*610*150

90-90

126 pcs / 175 銕

Remark: All kinds of panels can be customized by customers' specific requirement,

Features and Advantages of EPS Cement Wall Panel:


1. Fast construction (25m2/day/person)
2. Windproof (65m/s)
3. Sound insulation(46dB)
4. Anti-impact, Anti-seismic (class: 8)
5. Waterproof, Fireproof (4 hours, under 1000 degree centigrade)
6. Light weight, Energy-saving
7. Eco-friendly green material
8. Save area, Easy installation
9. Heat insulation & preservation
10. Strong and durable, 70 years life span.

Application of EPS Wall Panel:

Eps ceramsite sandwich panels can be widely used as roof, floor, interior wall, exterior wall, prefab house, high-rise building, villa, etc, especially for the unsafe area.

Business Organizations supermarket, large-scale shopping malls, exclusive agency, chain shops,
large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations Banks, negotiable securities, funds, insurance companies, pawnshops;
Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places subway, airports, stations, gas stations, toll stations, bookstores, parks,
exhibition halls, stadiums,museums, convention centers, ticket agencies,
HR market, lottery centers; Real Estate Property:
Apartments, villas, offices, commercial buildings, model rooms;
Entertainments Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars,
cafes, Internet bars, beauty shops, golf course


Windproof precast insulated concrete panels With Calcium Silicated Boards
Vanjoin Insulated Precast Concrete Wall Panels for House(for interior wall, exterior wall)
Windproof precast insulated concrete panels With Calcium Silicated Boards

Type Specification:

Different Types

Different Panels

Type 1

EPS cement sandwich panel

Type 2

Solid eps cement sandwich panel

Type 3

Ceramisite sandwich panel

Type 4

Solid Ceramisite sandwich panel

Type 5

Perlite sandwich panel

Type 6

Solid perlite sandwich panel

Type 7

Eps & Ceramicite Sandwich Panel

Type 8

Solid Eps & Ceramicite Sandwich Panel


FAQ of EPS Cement Panel
1. What's the annual capacity of lightweight precast concrete panels?
Our eps sandwich panel with annual production capacity of 6,000,000m2, ranking TOP 2 in China.

2 . Main market of Vanjoin lightweight precast concrete panels?
Main market : Asia, South Amercia, Africa, South East Asia, Middle East.

3. Certificate of Vanjoin lightweight precast concrete panels
We get CE, ISO9001, ISO1004, BV, , Patent certificates. We also passed the fireproof, Sound
insulation and other performance test by the Philippines Science and Technology Department.
